DeVilbiss 10 LPM Oxygen Concentrator

Detailed Description

The DeVilbiss 10 LPM Oxygen Concentrator is engineered to support both single and dual-patient oxygen therapy with flows up to 10 LPM per port. Utilizing Pressure Swing Adsorption (PSA) technology, it delivers ≥ 93 % ± 3 % oxygen purity continuously, making it suitable for high-demand applications such as COPD management, post-surgical support, and acute respiratory care.

Designed for uninterrupted 24/7 use, the robust compressor and dual molecular sieve beds ensure consistent performance even under heavy loads. Noise output remains low—approximately 55 dB at maximum flow—to provide a quieter environment for patients. Individual rotary flow knobs allow independent adjustment from 0.5–10 LPM on each outlet, while bright LED indicators display power status, oxygen purity warnings, and alarm conditions.

Key Features

• High Oxygen Purity: Produces ≥ 93 % ± 3 % at flow rates up to 10 LPM.

• Dual-Outlet Flow: Two independent 0.5–10 LPM flow ports for simultaneous dual-patient use.

• Continuous 24/7 Operation: Hospital-grade reliability for home and clinical settings.

• Noise Level: ≤ 55 dB at 10 LPM, designed for minimal disturbance.

• Simple Analog Controls: Individual flow knobs for each outlet with clear LED status indicators.

Configurations

• Flow Outlets:

  • Port A: 0.5–10 LPM; independent flow knob and LED purity indicator

  • Port B: 0.5–10 LPM; independent flow knob and LED purity indicator

• Humidification:

  • Built-In Ports: Two standard 22 mm humidifier bottle connections (bottles sold separately)

  • Optional Heated Humidifier: Compatible with DeVilbiss heated humidifier accessories

• Safety & Alarm Features:

  • Oxygen Purity Alarm: Audible/visual alarm triggers if purity drops below 85 %

  • High/Low Pressure Alarm: Monitors inlet and exhaust pressures for safe operation

  • Power Failure Alarm: Alerts on mains interruption or unstable input

• Maintenance & Service:

  • External Cabinet Filter: Snap-on filter cover, tool-free removal for cleaning

  • Sieve Bed Replacement: Service indicator LED alerts when PSA beds require replacement (recommended every 3 years or 20,000 hours)

  • Annual Preventive Maintenance: By authorized technician to ensure continued performance
